Titan Diamond 10R


Titan Diamond 10R

$1,400.00

Light Source

  • Lamp: Discharge short arc lamp with integrated reflector
  • Recommended Lamp: Osram Sirius HRI 280 W RO
  • Lamp Life Expectancy: Standard mode (280 W) - 2.000 hrs, Eco mode (230 W) - 3.000 hrs
  • Control: Automatic and remote on/off, default on power- off
  • Ballast: Electronic

Optics

  • High efficiency optics with dichroic glass to maximize output
  • Zoom range: 5˚- 25˚

Attributes

  • Colour wheel: 13 dichroic filters + white
  • Rotating Gobo wheel: 9 rotating, indexable and replaceable "SLOT&LOCK" glass gobos + open
  • Static Gobo wheel: 14 gobos + open
  • Prism 1: 8-facet circular prism rotating in both directions at different speeds
  • Prism 2: 6-facet linear prism rotating in both directions at different speeds
  • Frost effect: Separate
  • Dimmer/Shutter: Full range dimming and variable strobe effect
  • Motorized zoom and focus
  • Pan: 540°
  • Tilt: 270°

Thermal Information

  • Maximum ambient temperature: 45 °C (104 °F)
  • Maximum surface temperature: 100 °C (212 °F)

Electrical Information

  • Power supply: Electronic auto-switching
  • Input voltage range: 100–240 V, 50/60 Hz
  • Power consumption: 470 W at 230 V / 50 Hz

Physical Information

  • Height: 575 mm (22.6") – head in vertical position
  • Width: 364 mm (14.3")
  • Depth: 250 mm (9.8")
  • Weight: 15 kg (33 lbs)
  • Locking option: Pan/Tilt-lock

Mounting Information

  • Mounting points: 2 pairs of ¼-turn quick locks
  • 2 x bracket with ¼-turn quick locks
  • 1 x Safety point
